HWEncoderX: Video Transcoder with GPU Hardware Acceleration (Intel QSV, NVENC, VAAPI)

HWEncoderX is a Docker container that allows you to automatically transcode videos to H.265 (HEVC) using your GPU with hardware acceleration, supporting VAAPI (Intel/AMD), NVENC (NVIDIA), and Intel Quick Sync (QSV). This allows processing only the video track, prioritizing quality while keeping the audio, subtitles, and chapters intact.

Features

• Support for Multiple GPUs: Compatible with Intel Quick Sync (QSV), NVIDIA NVENC, and VAAPI. If no compatible GPU is detected, the container stops and sends an error notification.
• Support for Multiple Input Formats: Compatible with .mkv, .mp4, .avi, .mov, and .mpeg files.
• Telegram Notifications: Sends welcome notifications, transcoding details (time, speed, quality), and errors during the process.
• Always Active Docker: The container remains active, constantly monitoring the input directory for new files.
• Automatic Quality Adjustment: Optimized adjustment to prioritize quality based on the input video bitrate using the global QUALITY variable.
• Error Handling and Space Verification: Checks disk space before transcoding and sends notifications if space is insufficient or if there are errors.
• Size Reduction: Transcodes to H.265 (HEVC) to reduce file size by up to 70%.
• Ideal for Media Servers: Compatible with Plex, Jellyfin, Emby, and more.
• Simple: Just mount the input and output folders, and HWEncoderX does all the work.
• Customizable Options: Manually define the quality using the QUALITY variable and select the preset to adjust speed and quality as needed.

Telegram Notification Configuration

To receive Telegram notifications, configure a bot and obtain your BOT_TOKEN and CHAT_ID. Follow these steps:

1. Create a new bot on Telegram using BotFather and follow the instructions until you get your BOT_TOKEN.
2. Obtain your CHAT_ID by sending a message to your bot, then using an API call like:

   https://api.telegram.org/bot<YOUR_BOT_TOKEN>/getUpdates

   Replace <YOUR_BOT_TOKEN> with your bot token to find your CHAT_ID in the response.

Requirements

You need a GPU compatible with VAAPI (Intel/AMD), NVENC (NVIDIA), or Intel Quick Sync (QSV). Without a compatible GPU, the container will not work.

Parameters

Parameters	Requirement	Function
--device=/dev/dri	Required if using QSV or VAAPI	Needed to enable hardware acceleration through Intel Quick Sync (QSV) and VAAPI.
--gpus all	Required if using NVENC	Needed to enable hardware acceleration through NVENC on NVIDIA GPUs.
-v /path/to/input:/input	Required	Replace /path/to/input with the path to your input folder where the videos to be transcoded are located.
-v /path/to/output:/output	Required	Replace /path/to/output with the path where the transcoded files will be saved. (This can be the same as the input folder)
-e PRESET	Optional	Specifies the preset value (ultrafast, superfast, veryfast, faster, fast, medium, slow, slower, and veryslow). medium is the default value.
-e QUALITY	Optional	Manually define the quality level for transcoding, used in NVENC, VAAPI, and QSV. If not defined, the quality will be automatically adjusted based on the input bitrate to maintain an optimal balance between quality and file size.
-e BOT_TOKEN	Optional if notifications are desired	The token of your Telegram bot for sending notifications.
-e CHAT_ID	Optional if notifications are desired	The chat ID where Telegram notifications will be sent.
-e NOTIFICATIONS	Optional	Set to all to receive all notifications; if not defined, only error notifications will be sent.

Note: /path/to/input and /path/to/output can be the same folder. Transcoded files will be created with the _HEVC suffix.

Usage Instructions

Intel Quick Sync (QSV), VAAPI Usage

Docker Run

docker run -d --name hwencoderx --device=/dev/dri \
  -v /path/to/input:/input \
  -v /path/to/output:/output \
  -e BOT_TOKEN=xxxxxxxxxxxxxxxxxxxxxxxxxx \
  -e CHAT_ID=xxxxxxxx \
  -e QUALITY=18 \
  -e PRESET=medium \
  -e NOTIFICATIONS=all \
  macrimi/hwencoderx:latest

# Explanation of the parameters used:
# - `-e QUALITY=18`: Optional. Defines the custom quality level (recommended between 16 to 22) for transcoding.
# - `-e PRESET=medium`: Optional. Defines the custom preset for transcoding (optional).
# - `-e BOT_TOKEN=xxxxxxxxxxxxxxxxxxxxxxxxxx`: Optional. Replace with your TOKEN, requires CHAT_ID.
# - `-e CHAT_ID=xxxxxxxx`: Optional. Replace with your CHAT_ID, requires BOT_TOKEN.
# - `-e NOTIFICATIONS=all`: Optional.

docker-compose.yml

version: '3.3'

services:
  hwencoderx:
    image: macrimi/hwencoderx:latest
    container_name: hwencoderx
    restart: unless-stopped
    devices:
      - /dev/dri:/dev/dri
    volumes:
      - /path/to/input:/input
      - /path/to/output:/output
    environment:
      QUALITY: "18" # Optional
      PRESET: "medium" # Optional
      BOT_TOKEN: "xxxxxxxxxxxxxxxxxxxxxxxxxx" # Optional (replace with your TOKEN, requires CHAT_ID)
      CHAT_ID: "xxxxxxxx" # Optional (replace with your CHAT_ID, requires BOT_TOKEN)
      NOTIFICATIONS: "all" # Optional

NVIDIA Usage

Docker Run

docker run -d --name hwencoderx --gpus all \
  -v /path/to/input:/input \
  -v /path/to/output:/output \
  -e BOT_TOKEN=xxxxxxxxxxxxxxxxxxxxxxxxxx \
  -e CHAT_ID=xxxxxxxx \
  -e QUALITY=18 \
  -e PRESET=medium \
  -e NOTIFICATIONS=all \
  macrimi/hwencoderx:latest

# Explanation of the parameters used:
# - `-e QUALITY=18`: Optional. Defines the custom quality level (recommended between 16 to 22) for transcoding.
# - `-e PRESET=medium`: Optional. Defines the custom preset for transcoding.
# - `-e BOT_TOKEN=xxxxxxxxxxxxxxxxxxxxxxxxxx`: Optional. Replace with your TOKEN, requires CHAT_ID.
# - `-e CHAT_ID=xxxxxxxx`: Optional. Replace with your CHAT_ID, requires BOT_TOKEN.
# - `-e NOTIFICATIONS=all`: Optional.

docker-compose.yml

version: '3.3'

services:
  hwencoderx:
    image: macrimi/hwencoderx:latest
    container_name: hwencoderx
    restart: unless-stopped
    deploy:
      resources:
        reservations:
          devices:
            - capabilities: [gpu]
    volumes:
      - /path/to/input:/input
      - /path/to/output:/output
    environment:
      QUALITY: "18" # Optional
      PRESET: "medium" # Optional
      BOT_TOKEN: "xxxxxxxxxxxxxxxxxxxxxxxxxx" # Optional (replace with your TOKEN, requires CHAT_ID)
      CHAT_ID: "xxxxxxxx" # Optional (replace with your CHAT_ID, requires BOT_TOKEN)
      NOTIFICATIONS: "all" # Optional

Additional Notes

HWEncoderX works with hardware acceleration VAAPI, NVENC, and QSV. Without a compatible Intel, AMD, or NVIDIA GPU, the container will not work. Original files are not deleted after transcoding, allowing you to keep both the original and the transcoded files with the _HEVC suffix.

Synology/XPenology NAS Compatibility

Works on any NAS with a functional Intel or NVIDIA GPU.

DVA Models

On DVA Synology NAS that use the NVIDIA Runtime Library for Surveillance Station, it is not possible to run this container as they do not have NVIDIA Container Toolkit.

License

This project is under the MIT License. You are free to use, modify, and distribute the code as long as proper credit is given. See the LICENSE file for more details.

Third-party Software

This container uses FFmpeg, licensed under LGPL 2.1 or later. See the FFmpeg documentation for more information.
