POC: Xamarin.Forms Page Factory Concept

Intro

Some apps might have several pages which follow the same pattern, the idea of this concept is to have a factory that produces these pages for you without the need to design them manually.

Background

While working for a customer, we have got an assignment to make a complaint app. It has a web version, which kind of long with some questions followed by other questions. To make easier for the user , the fields are grouped by relevence.

Unlike the web where space is not an issue, space is a serious issue when it comes to mobile apps , after all how big can a mobile screen be . Therefore to overcome this issue we decided to create a page for every group of questions, For example questions regarding the general information would be in a GeneralInformationPage , information about product can be in a ProductInformationPage and so on. In our specific project that means we need to create more than 15 pages which are resposible to fill data of more than 15 grouped information about the complaint. At that piont the idea of having a page factory came to light.

FAQ

• When is this method recommended to be used? le apps with several pages which has the same purpose, can be used in Industrial apps, or apps for questionnaires, or any data entry apps that that beauty and interactivity are not the main focus .

• When is this method Not recommended to be used? Apps with few number of pages , apps with very sophisticated design and styles, or Apps with pages that are totally different from each other and not many similar pages.

• How mature is this code? Not at all , this is just a POC to show how the PageFactory works .

• Can we integrate it with MVVM framework like Prism? Yes. There is already a poc that has a PrismApp where the PageFactory is used. Check PageFactoryForPrismRepository

• How about the performance? Our first tests in a low end PC showed that after the app launches, it takes longer time to generate the first produced page than usual. However after that all the pages are produced instantly just like as if they were already written. There is a slight chance that

• How can this concepts be improved?

  Many things can make the concept better, to start with more attributes, for example attributes for Image,or List attributes, attributes for page type as currently it is only for ContentPage.

  Another improvement can be to have PageFactory in its own nugetPackage .

  We can think of the custom controls , should they be part of the PageFactory Nuget ? or shall we have a mechanism to connect the Attributes with the visual elements in a dynamic way somehow ?

• What is the highest ambition for the PageFactory Approach? To have a standard page factory component, and a view-less M-V-VM pattern.

• Why have you placed the FAQ on top of the document? So people would have more ideas and less assumbtions before proceeding with reading the document.

PageFactory Concepts

• Page Factory This is the class where it takes viewmodels, produces pages based on the properties and their attributes, and bind the pages to their viewmodels . The factory can also used for navigation and it keeps track of the pages.

• Produced Pages Pages which are produced by the Page Factory on the run time.

• ViewModels View models are the main source of information for a page factory in view model , you can decide what properites to be shown or not , how they are going to be showen (e.g. is it required) , and in what order are they shown.

• Attributes The attributes are custom attributes made by the developer . The page factory will look for attributes decorating the properties in the viewmodel to decide how the properties will be represented . For example, having a Required attribute on the property would direct the PageFactory to have the required label activated on the field.

 public class RequiredAttribute : Attribute
 {
 }

If the property has no attributes then the PageFactory should ignore it .

Applying the PageFactory concept

Have a look at our repository and you will see there are two Projects ComplaintApp and ComplaintAppPageFactory .

As you might guessed they are the same application but the second one applies the PageFactory concept

• Finding the pages which have the same pattern if we look closely we can find that MainPage, GeneralInformationPage, ProductInformationPage and ClientInformationPage have the same pattern; they are pages that has a table view with different cells to represent the data. Some of these cells are required and some are not . They also use custom controls to present the data.

• Creating attributes to decorate the viewmodel Now you need to create some custom attributes to decide how each property should be presented , so far we have the following attributes and of course there should be more to cover more cases

  Attribute	Description
  SwitchAttribute	The element is a switch
  CommandAttribute	The element has a Command Property
  DateAttribute	The element is a DatePicker
  LabelAttribute	The element is a label
  EntryAttribute	The element is Entry
  LongTextAttribute	The element is Editor
  TitleAttribute	The title of the element and it can be applied on the page level and the button by decorating the class of the VM and the command property
  RequiredAttribute	This will enable the required functionality of the element.

• Decorating the View-Models with the attributes Now we can add the attributes to the properties of each View-model of the pages we .

  The Title attribute can be applied on the class level and that will give a title to the page. If we apply the title attribute to the command level, the page factory with crate a button and give it the title.

• Create your page factory

  Here is our implementation for the page factory

public interface IPageFactory
{
    Page CreatePage<T>() where T : INotifyPropertyChanged;
    Page CreatePage(Type type);
    Page CreatePage(INotifyPropertyChanged viewModel, Type type);
    Task NavigateAsync(Page nextPage, bool isAnimated = true);
    Task NavigateAsync<TDestination>(bool isAnimated = true) where TDestination : INotifyPropertyChanged;
    Task<bool> ShowAlert(string title, string message, string ok, string cancel = "");
}
public class PageFactory : IPageFactory
    {
        public Page CreatePage<T>() where T : INotifyPropertyChanged
        {

            return CreatePage(typeof(T));
        }

        public Page CreatePage(Type type)
        {
            var viewModel = Activator.CreateInstance(type);
            return CreatePage((INotifyPropertyChanged)viewModel, type);
        }

        public Page CreatePage(INotifyPropertyChanged viewModel, Type type)
        {
            var page = new ContentPage();
            var tableView = new TableView {HasUnevenRows = true};
            var tableRoot = new TableRoot();
            var tableSection = new TableSection();

            var stackLayout = new StackLayout();
            page.Content = stackLayout;
            page.BindingContext = viewModel;

            if (type.CustomAttributes.Any(c => c.AttributeType == typeof(TitleAttribute))) // Page Level
            {
                var titleAttribte = type.CustomAttributes.Single(c => c.AttributeType == typeof(TitleAttribute));
                page.Title = titleAttribte.ConstructorArguments[0].Value.ToString();
            }

            foreach (var propertyInfo in type.GetProperties())
            {
                if (!propertyInfo.CustomAttributes.Any()) continue;
                var child = new RequiredCell();
                var isRequired = false;
                var title = "";

                foreach (var attribute in propertyInfo.CustomAttributes)
                {
                    switch (attribute.AttributeType.Name)
                    {
                        case nameof(TitleAttribute):
                            title = attribute.ConstructorArguments[0].Value.ToString();
                            break;
                        case nameof(RequiredAttribute):
                            isRequired = true;
                            break;
                        case nameof(LabelAttribute):
                            child = new RequiredLabelCell();
                            child.SetBinding(RequiredLabelCell.TextProperty, propertyInfo.Name, BindingMode.TwoWay);
                            break;
                        case nameof(EntryAttribute):
                            child = new RequiredEntryCell();
                            child.SetBinding(RequiredEntryCell.TextProperty, propertyInfo.Name, BindingMode.TwoWay);
                            break;
                        case nameof(LongTextAttribute):
                            child = new RequiredEditorCell();
                            child.SetBinding(RequiredEditorCell.TextProperty, propertyInfo.Name, BindingMode.TwoWay);
                            break;
                        case nameof(SwitchAttribute):
                            child = new RequiredSwitchCell();
                            child.SetBinding(RequiredSwitchCell.IsToggledProperty, propertyInfo.Name, BindingMode.TwoWay);
                            break;
                        case nameof(DateAttribute):
                            child = new RequiredDatePickerCell ();
                            child.SetBinding(RequiredDatePickerCell.DateProperty, propertyInfo.Name, BindingMode.TwoWay);
                            break;
                        case nameof(CommandAttribute):
                            var commandName = attribute.ConstructorArguments[0].Value.ToString();
                            var command = (ICommand)type.GetProperties().Single(p => p.Name == commandName).GetValue(viewModel);
                            child.Command = command;
                            break;
                    }
                }
                child.Title = title;
                child.IsRequired = isRequired;
                //Add the button
                if (propertyInfo.PropertyType == typeof(ICommand) || propertyInfo.PropertyType == typeof(Command))
                {
                    var command = (ICommand) propertyInfo.GetValue(page.BindingContext);
                    var button = new Button
                    {
                        Text = title,
                        Command = command
                    };
                    child = new RequiredCell
                    {
                        View = button
                    };
                }

                tableSection.Add(child);
            }

            tableRoot.Add(tableSection);
            tableView.Root = tableRoot;
            stackLayout.Children.Add(tableView);
            return page;
        }

        public async Task NavigateAsync<TDestination>(bool isAnimated = true) where TDestination : INotifyPropertyChanged
        {

            var nextPage = CreatePage<TDestination>();
            if (Application.Current.MainPage is NavigationPage navigationPage)
            {
                await navigationPage.CurrentPage.Navigation.PushAsync(nextPage, isAnimated);
            }
        }

        public async Task NavigateAsync(Page nextPage, bool isAnimated = true)
        {

            if (Application.Current.MainPage is NavigationPage navigationPage)
            {
                await navigationPage.CurrentPage.Navigation.PushAsync(nextPage, isAnimated);
            }
        }

        public async Task<bool> ShowAlert(string title, string message, string ok, string cancel ="")
        {
            if (!(Application.Current.MainPage is NavigationPage navigationPage)) return false;
            if (!string.IsNullOrEmpty(cancel))
            {
                return await navigationPage.CurrentPage.DisplayAlert(title, message, ok, cancel);

            }
            return await navigationPage.CurrentPage.DisplayAlert(title, message, null, ok);
        }
    }

• • For the sake of having a POC the Page Factory produces only ContentPage
  • PageFactory does not only creates pages, but also handles Alerts and Navigation so that they could be called from the view-model .
  • If you change the order of the properties in the viewmodel then order of the elements in the page will change accordingly, this sounds like a wierd thing but turned to be a cool feature.

• Apply the PageFactory concept on the view models.

You can start by removing the event handlers which the code behind listens to so it can navigate, and use the navigation methods given by the page factory. Look at the changes we did in MainPageViewModel

• Remove the views which we targeted earlier

  So this case MainPage, GeneralInformationPage, ProductInformationPage and ClientInformationPage are removed.

• Give it a go

Pros and Cons

Pros

• Code Reduction If you have multiple pages that can be produced with the Pagefactory then you will basically remove view code for these pages .

• Flexibility The flexibility gets higher, you can change a feild on a page from one type to another type only by change the decorating attributes , you can change the order of the fields but just changing the order of the properties. Adding new feilds is easier and quicker.

• More focus on logic When you get to focus only on the viewmodel , the business logic will get more focus by the developer than if there was a view presenting the view model , where the developer should make sure that the bindings are correct and if everything is in the right order

• Fewer human errors Of course when our pages are generated automatically it means that less human interaction is required and thus fewer errors from the developers .

Cons

• Complexity of the PageFactory Class More attributes created means more work has to be done in the PageFactory class where it has to recognize the new attributes and takes the right decision. This issue can be addressed by finding a good pattern to write the PageFactory class.

• Not suitable for small apps This concept probably will not be the best choice if the app has few pages or there is no common pattern among them.
