Python VS KNIME

Summary

A GitHub repository to show comparison between models exported from KNIME and Python. Python provides the flexibility, while KNIME provides the simplicity with its codeless system.

Things to compare:

1. Train deep learning models using Keras in Python and export to KNIME.
2. Load the deep learning models exported from KNIME to evaluate the results in Python.
3. Repeat steps 1-2 for a conventional machine learning model (e.g. Decision Tree)
4. Compare the evaluation results done in Python and KNIME.
5. Export the Python models to test it in KNIME too.

NOTE: The models should have exactly the same parameters if possible for the best results.

There are two notebooks: Decision Tree Comparison.ipynb for comparing Decision Tree models, and MNIST Digit Classification.ipynb for comparing CNN models trained in Keras in both KNIME and Python.

Installation

TensorFlow library for loading and training of deep learning models. Refer to the YouTube video here for detailed instructions to install TensorFlow with GPU support.

Using sklearn-pmml-model library from here, to load PMML model. Follow the installation steps explained in that GitHub repo.

Using sklearn2pmml library from here to create PMML model.

Comparison Results

You may refer to the results folder for each of the individual confusion matrix for different models.

Notes on Deep Learning Models

• The MNIST images obtained from KNIME are named differently than usual, i.e. Row0.png, Row1.png, ... , Row9999.png. Be careful that sorting the filenames by using only the vanilla sorted function (without using a custom sorting method with the key argument) would result in an incorrect order of the images when compared to their corresponding labels.
• When comparing deep learning models, be careful that the default parameters/config in KNIME could be different from Python, such as in the case of Adadelta optimizer: the default learning rate in Python is 0.001, but 1.0 in KNIME.
• The training and evaluation results for Adadelta were noticeably different (about 2-3%) between KNIME and Python for some unknown reasons, most likely because of different Keras version used in the backend of KNIME.

About the Exported Model from KNIME

• The exported deep learning models from KNIME can only be either the SavedModel format, or the Keras .h5 format. The h5 format can retain all the functionalities associated with the Keras framework, such as being able to check all the layers by calling model.summary() method. While the SavedModel format will have limited functionalities and you would need to extract the model function from the model.signatures['serve'] key to be able to run inference. Please refer to the last two sections of the MNIST Digit Classification.ipynb notebook for the detailed steps.
• You might need to downgrade NumPy's version to below 1.20 if you experienced error like below when trying to load the Keras h5 model exported from KNIME. Link to the issue here.

NotImplementedError: Cannot convert a symbolic Tensor (lstm_1/strided_slice:0) to a numpy array. This error may indicate that you're trying to pass a Tensor to a NumPy call, which is not supported

Notes on Machine Learning Models in PMML format

• You must install the sklearn-pmml-model library from here, to load PMML model.
• You must also install the sklearn2pmml library from here to convert from sklearn pipeline to a PMML model.
• Both of these libraries are the best solutions that I have found for now, things might change and you might need to find other alternatives in the future.
• For the detailed steps of how to load and export PMML model, please refer to the Decision Tree Comparison.ipynb notebook.
• Be careful that KNIME might use different model parameters/implementations from sklearn models and many parameters cannot be changed easily in sklearn to follow the parameters used by KNIME.
• The Decision Tree Learner application used in KNIME also automatically encodes the nominal/categorical columns and I couldn't find any reference on how exactly they encode them. Therefore, in the experiment done in this repo, I used OrdinalEncoder to encode the columns before I use the KNIME's Decision Tree Model to make inference, but the performance result was slightly different.
• On the other hand, the Decision Tree model that I trained in Python has to drop the categorical columns in order to achieve similar performance as the KNIME's model.
