open-fdd

Config-driven FDD for HVAC — YAML fault rules, pandas DataFrames, and optional Brick model–driven column mapping.

Pandas is an excellent choice for high-performance, tabular computing and rule-based fault detection. If you know Python and love pandas, you'll feel right at home — especially if you're a visual or spatial thinker (or both) who likes to see data in tables and trace logic through expressions. pandas provides fast, spreadsheet-like DataFrames for cleaning, wrangling, analyzing, and computing on time-series data using simple, Excel-style operations at scale; it was created in 2008 by Wes McKinney while working in finance to handle large time-series datasets more efficiently and later became a core project in the scientific Python ecosystem under the NumFOCUS foundation.

open-fdd is under construction with daily updates. Stay tuned for version 2.0! Be sure to check out the new online docs!

Quick Start

Map BRICK class names to your raw BAS column headers (e.g. SAT (°F), SF Spd Cmd (%)), then run rules:

import pandas as pd
from pathlib import Path
from open_fdd import RuleRunner
from open_fdd.engine import load_rule
from open_fdd.reports import summarize_fault, print_summary

# Raw BAS point names (as exported from your BMS)
df = pd.DataFrame({
    "timestamp": [
        "2023-01-01 00:00", "2023-01-01 00:15", "2023-01-01 00:30", "2023-01-01 00:45",
    ],
    "SA Static Press (inH₂O)": [0.4, 0.4, 0.2, 0.2],
    "SA Static Press SP (inH₂O)": [0.5, 0.5, 0.5, 0.5],
    "SF Spd Cmd (%)": [0.95, 0.95, 0.95, 0.95],
})

# BRICK class -> raw BAS column name
column_map = {
    "Supply_Air_Static_Pressure_Sensor": "SA Static Press (inH₂O)",
    "Supply_Air_Static_Pressure_Setpoint": "SA Static Press SP (inH₂O)",
    "Supply_Fan_Speed_Command": "SF Spd Cmd (%)",
}

rules_dir = Path("open_fdd/rules")
runner = RuleRunner(rules=[load_rule(rules_dir / "ahu_fc1.yaml")])
result = runner.run(
    df,
    timestamp_col="timestamp",
    column_map=column_map,
    rolling_window=3,  # fault only if true for 3+ consecutive samples
)
summary = summarize_fault(
    result,
    "fc1_flag",
    timestamp_col="timestamp",
    motor_col=column_map["Supply_Fan_Speed_Command"],
)
print_summary(summary, "FC1 Low Duct Static")

Rule expression example (FC9)

Rules use BRICK class names in inputs; column_map maps them to your raw BAS columns:

name: oat_too_high_free_cooling
type: expression
flag: fc9_flag
equipment_type: [AHU, VAV_AHU]

inputs:
  oat:
    brick: Outside_Air_Temperature_Sensor
    column: OAT (°F)
  sat_setpoint:
    brick: Supply_Air_Temperature_Setpoint
    column: SAT SP (°F)
  economizer_sig:
    brick: Damper_Position_Command
    column: OA Damper Cmd (%)
  cooling_sig:
    brick: Valve_Command
    column: Clg Vlv Cmd (%)

params:
  outdoor_err_thres: 1.0
  delta_t_supply_fan: 0.5
  supply_err_thres: 1.0
  ahu_min_oa_dpr: 0.1

expression: |
  (oat - outdoor_err_thres > sat_setpoint - delta_t_supply_fan + supply_err_thres) & (economizer_sig > ahu_min_oa_dpr) & (cooling_sig < 0.1)

# column_map: BRICK class -> raw BAS column (as exported from BMS)
column_map = {
    "Outside_Air_Temperature_Sensor": "OAT (°F)",
    "Supply_Air_Temperature_Setpoint": "SAT SP (°F)",
    "Damper_Position_Command": "OA Damper Cmd (%)",
    "Valve_Command": "Clg Vlv Cmd (%)",
}

With Brick TTL, use resolve_from_ttl("model.ttl") instead of a manual column_map.

Getting Started

Please see the online docs for setup and running HVAC fault checks with pandas.

📖 Docs

Dependencies

pandas · PyYAML · optional: matplotlib (viz), rdflib (Brick TTL)

Contributing

Open FDD is under construction but will be looking for testers and contributors soon, especially to complete a future open-source fault rule cookbook.

License

MIT
