Flexiv TDK

Flexiv TDK (Teleoperation Development Kit) is an SDK for building custom robot-to-robot or device-to-robot teleoperation applications with Flexiv's adaptive robots. It enables synchronized, force-guided motion using high-fidelity perceptual feedback and supports both LAN (Local Area Network) and WAN (Internet) connections.

🎬 Flexiv's TDK | Teleoperation Made Simple
(Click image below to play)

---

✅ Compatibility

OS	Processor	Languages	Compiler Requirements	Python Versions
Ubuntu 22.04+	x86_64, aarch64	C++, Python	GCC ≥ 9.4, CMake ≥ 3.16.3	3.8, 3.10, 3.12

💡 Need support for other platforms? Contact Flexiv.

---

⚙️ Kernel Options for Real-Time Performance

Ubuntu offers multiple kernel variants tailored for different workloads:

Kernel Type	Description	Typical Use Case
generic	Default kernel: balanced performance & power management	General desktop/server use
lowlatency	Reduced interrupt latency; better scheduling responsiveness	Robotics, audio processing, soft real-time
rt (PREEMPT_RT)	Fully preemptible; hard real-time determinism	Industrial control, mission-critical systems

---

⚠️ Important Disclaimer

Upgrading to a low-latency or real-time (RT) kernel may:

• Break proprietary drivers (e.g., NVIDIA, Wi-Fi modules)
• Cause system instability or boot failure

You assume full responsibility for any issues arising from kernel changes.
✅ Always back up your system before proceeding.

---

Install Low-Latency or PREEMPT_RT Kernel for Ubuntu/x84-64

Option 1: Low-Latency Kernel

1. Install the kernel: For Hardware Enablement (HWE) stack (check with uname -r; e.g., Ubuntu 22.04 with kernel 6.x), use:

   sudo apt update && sudo apt install --install-recommends linux-lowlatency-hwe-22.04  # replace "22.04" with your version

   For the original kernel (5.15), use:

   sudo apt update && sudo apt install --install-recommends linux-lowlatency

2. Set GRUB to prefer low-latency:

    echo 'GRUB_FLAVOUR_ORDER="lowlatency"' | sudo tee -a /etc/default/grub
    sudo update-grub

3. Reboot and verify:

   sudo reboot
   uname -r  # Should show "...-lowlatency"

   🔄 To revert to generic, change GRUB_FLAVOUR_ORDER="generic" and run sudo update-grub.

Option 2: PREEMPT_RT Kernel

Follow the official guide:
🔗 Real-time Ubuntu Setup (Documentation)

ℹ️ Ubuntu 22.04/24.04 users can enable RT kernel via free Ubuntu Pro subscription.
Ubuntu 20.04 requires manual patching (advanced users only).

ℹ️ For Nvidia Jetson(arrch64), please refer to Nvidia's official documentation.

---

🚀 Quick Start - Python

1. Install the Python package

On all supported platforms, the Python package of TDK and its dependencies for a specific Python version can be installed using the pip module:

python3.x -m pip install spdlog flexivtdk

NOTE: replace 3.x with a specific Python version.

2. Use the installed Python package

After the flexivtdk Python package is installed, it can be imported from any Python script. Test with the following commands in a new Terminal, which should start Flexiv TDK:

python3.x
import flexivtdk
flexivtdk.__version__

3.🕒 System Clock Sync

Accurate time sync is critical for teleop over the internet. For WAN teleop, there are two edge computers, one acting as a server and the other as a client, and the system time of these two computers needs to be calibrated.

Note: This is only required for WAN Teleoperation, users can skip this section if only using LAN teleoperation.

1. Install & Start chrony

sudo apt install chrony -y
systemctl status chrony  # Should show "active (running)"

2. Check Sync Accuracy

chronyc tracking | grep 'System time\|RMS offset'

System time: the instantaneous offset between local system clock and NTP reference

RMS offset: the long-term average offset (root mean square) over time

Network Condition	Good (ms)	Acceptable (ms)	Poor (ms)
System time	< 1	1 - 10	> 10
RMS offset	< 5	5 - 20	> 20

3. Force Immediate Sync (if needed)

sudo chronyc burst 4/4
sudo chronyc makestep

🔄 After network changes (e.g., Wi-Fi → Ethernet), restart:

sudo systemctl restart chronyd
sleep 5
sudo chronyc makestep

4. Learn more: Chrony Documentation

4. Enable Real-Time Privileges for Non-root Users

To allow a regular user to create high-priority (real-time) threads without sudo, configure system to apply real-time and nice priority limits:

echo "${USER}    -   rtprio    99" | sudo tee -a /etc/security/limits.conf
echo "${USER}    -   nice     -20" | sudo tee -a /etc/security/limits.conf

Log out and log back in (or reboot) for the settings to take effect.

5. Run example Python scripts

To run an example Python script in this repo:

cd flexiv_tdk/example_py
python3.x <example_name>.py [arguments]

Check each example’s source code for usage details.

🚀 Quick Start - C++

The TDK is distributed as a modern CMake project named flexiv_tdk.

1. Install Build Dependencies

sudo apt install build-essential cmake cmake-qt-gui -y

2. Choose an Installation Directory

Example: ~/tdk_install

3. Build & Install Third-Party Dependencies

cd flexiv_tdk/thirdparty
bash build_and_install_dependencies.sh ~/tdk_install

4. Configure & Install TDK

cd flexiv_tdk
mkdir build && cd build
cmake .. -DCMAKE_INSTALL_PREFIX=~/tdk_install
cmake --build . --target install --config Release

🌐 Internet connection to GitHub is required for 3. Build & Install Third-Party Dependencies and 4. Configure & Install TDK.

5. Link TDK in Your Project

After the TDK library is installed, it can be found as a CMake target and linked to from other CMake projects. Using the provided examples project for instance:

cd flexiv_tdk/example
mkdir build && cd build
cmake .. -DCMAKE_PREFIX_PATH=~/tdk_install
cmake --build . --config Release -j 4

NOTE: -D followed by CMAKE_INSTALL_PREFIX tells the user project's CMake where to find the installed TDK library.

6. Run Examples

cd flexiv_tdk/example/build
./<program_name> [arguments]

Check each example’s source code for usage details.

📚 Generate API Documentation

sudo apt install doxygen-latex graphviz
cd flexiv_tdk
doxygen doc/Doxyfile.in

Open flexiv_tdk/doc/html/index.html in your browser.
