TileMapLayer3D 🧩

Godot 4.5+ editor plugin for building 3D tile-based levels from 2D tilesheets. Heavily inspired by Crocotile3D but built directly into Godot.

Join the Discord Server for more info: https://discord.gg/WKnxwrcJcn

Full user guide: HOW_TO_GUIDE.md

Video tutorial/overview (Please checck the HOW_TO_GUIDE for more up to date information):

Note: If you are migrating to a version earlier than v1.0, you may encounter corrupted data. Make sure you have a backup of your project. Ideally, from version 1.0, you should start with a clean scene and recreate your levels in v1.0+ if possible. There is an auto-migration in place, but it might not handle all edge cases of your scene.

Want to support me?

or via GitHub: Sponsor DanTrz

---

Tutorial and Auto-Tiling Setup Video

🎯 Why I created this?

To help with creating old-school 3D pixel-art games, or to leverage 2D tiles for fast level prototyping. You can build entire levels or reusable grid-based objects with perfect tile alignment.

---

✨ What it does

• Paint 3D levels from 2D tilesheets — load any tilesheet or Godot TileSet, select tiles, paint floors, walls, ceilings, and tilted ramps in the 3D viewport.
• Multiple mesh types — FLAT_SQUARE, FLAT_TRIANGULE, BOX_MESH, PRISM_MESH, plus experimental arch variants — for everything from flat floors to thick walls and angled slopes.
• Unified Godot TileSet — manual painting, AutoTile, custom data, animation, and runtime queries all use a single TileSet resource.

Workflow modes that go beyond a paint brush

• 🧠 AutoTile — paint terrain and let Godot's native terrain peering bits pick the right tile for you. Roads, walls, and grass borders just work.
• 🎞️ Animated Tiles — turn a strip of frames into a shader-driven animated tile. Drop a waterfall, lava, or torch and it animates in-engine runnning on GPU via shader.
• 🪄 Smart Operations — click one tile to select connected regions, replace them with a different texture in one shot, or generate full ramps between two points with Smart Fill → Fill Ramp.
• ⛰️ Sculpt Mode — brush-paint volumes: draw a footprint with the diamond, square, or arched brush, then drag up to extrude a building, hill, or platform in seconds.
• 🔷 Vertex Edit — convert any flat tile into a free-form quad and drag its four corners in 3D for custom shapes, sloped roofs, or organic terrain.

Built for real projects

• Regional collision and mesh baking — alpha-aware options for cut-out textures, per-region rebuilds, exportable baked meshes.
• Runtime API — place, erase, query, swap, and refresh collision from gameplay scripts
• Full undo/redo — every action reversible via the Godot editor.

For details on every mode, shortcut, and setting, see the HOW_TO_GUIDE.md.

---

🚀 Quick Start

1. Open your Godot 4.5+ project.
2. Go to Project → Project Settings → Plugins and enable TileMapLayer3D.
3. Create a 3D scene and add a TileMapLayer3D node under a Node3D.
4. Select the TileMapLayer3D node — the left vertical toolbar, the bottom context toolbar, and the TileMapLayer3D bottom panel will appear.
5. Pick Manual mode from the left toolbar.
6. In the bottom panel, click Load Texture (or Load TileSet), set your tile size, and select a tile.
7. Toggle On in the left toolbar.
8. Use WASD to move the 3D cursor and left-click to paint.

The left vertical toolbar is the primary navigation. The last option is Global Settings mode, which exposes collision, baking, and utility controls in the bottom panel.

---

🎮 Key Shortcuts

Key	Action
W / A / S / D	Move cursor (camera-relative)
Shift + W / Shift + S	Move cursor up / down
Left click / drag	Paint tile / stroke
Right click / drag	Erase tile / stroke
Shift + Left drag	Area paint
Shift + Right drag	Area erase
Q / E	Rotate 90° CCW / CW
R / Shift + R	Cycle tilt forward / backward
T	Reset to flat orientation
F	Flip tile face
Esc	Cancel area selection

Full shortcut and control reference: HOW_TO_GUIDE.md.

Credits

• SpriteMesh by 98teg — Godot plugin for creating 3D meshes from 2D sprites. MIT License.

📄 License

MIT
